Wiehle Avenue North area with an overlay of the NVSRB project area

Undermined culvert outlet on NOVA Hebrew Congregation property

Severe channel erosion at the bridge (slated for replacement) on Forest Edge Cluster property

Riprap outfall stabilization at North Shore Drive. Note 3' drop from apron to stream.

Severely incised channel: 6.5' deep

Severely incised channel: 7' deep with 2.5' headcut

Channel widening and subsequent tree loss from streambank erosion

Old riprap stabilization at an exposed sanitary sewer

Vertical cut banks more than 12' high

10' - 15' vertical banks at an old road bed

Exposed utility lines 3' above the stream channel

Deposition at Lake Anne outfall following Tropical Storm Lee in 2011

An incised channel through a gas line easement

Channel widening takes a toll on trees

In the past, riprap was installed to stop the advancement of a headcut in this trail-side tributary
